- Brand Name: NoEnName_Null
- Origin: Mainland China
- Hign-concerned Chemical: None
- DIY Supplies: Electrical
- Free installation service: Yes
- Place of Origin: Guangdong, China, GuangDong,China
- Application: Home/Farmacia/Granja/Industria y Comercio
- Solar Panel Type: Monocrystalline Silicon, Polycrystalline Silicon
- Battery Type: Lithium Ion, NONE
- Controller Type: MPPT, PWM
- Load Power (W): 20kw, 10KW, Others
- Output Voltage (V): 102V-400V, 51.2V
- Output Frequency: 50/60HZ
- Work Time (h): 24 Hours
- Pre-sales project design: Y
- Panel Dimensions: 851*255*(228+130*(N-1))
- Certificate: CE/TUV, TUV, ETL, CE, ISO, CE,MSDS,TUV,FCC
- Communication: CAN/RS485/DIY CONTACT
- Weight: 85+85*(N-1)
- Keyword: LiFePO4 Solar Battery
- Inverter: ALLITH
- Product name: Stacked
- Battery: Lifepo4/Lithium Ion Battery
- Warranty: 10 years
Model | LP-AI-512200 | ||||
Rated Output Power | 10000W | ||||
Parallel Capacity | 1-6 units(Max .60kw) | ||||
Rated Output/Input Voltage | single110/220V/split-phase240V/three-phase380V(optional) | ||||
Frequency Range | 50/60HZ | ||||
Switching Time | 10MS(typical) | ||||
MPPT Tracking Efficien | 99% | ||||
Num.of Mppt | 2 | ||||
Max.PV Array Power | 5500W+5500W | ||||
Max.Voltage of Open Circuit | 500Vdc+500Vdc | ||||
Mppt Voltage Range | 125-425Vdc | ||||
Battery Standard Voltage(V) | 51.2V | ||||
Communication | RS232/RS485/CAN(Optional Bluetooth/Wifi) | ||||
Energy(WH) | 10KWH | 30KWH | 50KWH | ||
Standard capacity(AH) | 200AH | 600AH | 1000AH | ||
Net weight of battery pack | 125Kgs | 295Kgs | 465Kgs | ||
cycles | ≥6000 at25℃ | ||||
Working Temperature | 0°℃-50℃ Charge | ||||
External Module (optional) | Wi-Fi / GPRS(optional) | ||||
Max Loaded Power | 10KW *N | ||||
Size(L*W*H) | 820*590*486 mm | 820*590*810 mm | 820*590*1134 mm | ||
⭐ Long life:designed service life is 15 years , cycle times is 6000+
⭐ High safety: can realize overcharge, over-discharge, over-current.short-circuit, and anti-reverse current protection.
⭐ Strong intelligence: Diversified working modes, and can realize real-time remote monitoring, remote control, and remote upgrade.
⭐ Super simple: stacked and integrated design, easy to install and use.
⭐ High safety: can realize overcharge, over-discharge, over-current.short-circuit, and anti-reverse current protection.
⭐ Strong intelligence: Diversified working modes, and can realize real-time remote monitoring, remote control, and remote upgrade.
⭐ Super simple: stacked and integrated design, easy to install and use.
Allith’s Profile
Huajiedongli is a new energy enterprise integrating research, development production and sales of lithium-ion
batteries.
1. In 2022, a battery cell production base and a power battery PACK production base was set up in Heng yang, Hunan Province, with a production area of more than 500.000 square meters, six fully automated cell production lines, and two PACK semi-automatic production lines, with an annual production capacity of 15GWh.
2. Build a R&D team of more than 30 people, and our service has been expanded to all over world.Our products are widely used in Germany,Spain,America,Italy, Australia,Zimbabwe, South Africa, Vietnam and many other countries and regions ,and have been extensively applied and highly appraised in a number of major projects.
3. The company has passed ISO9001, ISO14001, ISO45001 and other system certification.
4. The product has passed CE, UL, ROHS, IEC62613, UN38.3, MSDS and other certifications.
batteries.
1. In 2022, a battery cell production base and a power battery PACK production base was set up in Heng yang, Hunan Province, with a production area of more than 500.000 square meters, six fully automated cell production lines, and two PACK semi-automatic production lines, with an annual production capacity of 15GWh.
2. Build a R&D team of more than 30 people, and our service has been expanded to all over world.Our products are widely used in Germany,Spain,America,Italy, Australia,Zimbabwe, South Africa, Vietnam and many other countries and regions ,and have been extensively applied and highly appraised in a number of major projects.
3. The company has passed ISO9001, ISO14001, ISO45001 and other system certification.
4. The product has passed CE, UL, ROHS, IEC62613, UN38.3, MSDS and other certifications.
Want to know more about offers and product catalogs. You can contact us directly.
Allith staff are happy to serve you
