- Brand Name: DUTRIEUX
- Hign-concerned Chemical: None
- Origin: Mainland China
- Type: Non-Pressure
- Application: Water Heater
- after-sales service provided: Free spare parts
- warranty: 1 Year
- application: Outdoor, Hotel, Household
- power source: Electric, Solar
- app-controlled: NO
- logo/pattern: Laser Printing, 3D Printing
- type: Flat-Plate
- circulation type: Indirect / Closed Loop (Active)
- connection type: Split
- installation: freestanding
- Housing Material: Stainless Steel
- Capacity: 100
- place of origin: Zhejiang, China
- brand name: Jinneng
- model number: JINFP-100-1
- Product name: Solar Hot Water Heater
- Name: Split Solar Water Heater System
- Application: Washing
- Inner tank: SUS304-2B Stainless Steel
- Outer tank: Colour Galvanized Steel Plate
- Warranty: 5 Years
- Use: Shower Room
- Solar collector: Flat Planel
- Insulation layer: 55mm Foam Polyurethane
- Collector Insulating: Fiber Glass
#detail_decorate_root .magic-0{border-bottom-style:solid;border-bottom-color:#53647a;font-family:Roboto;font-size:24px;color:#53647a;font-style:normal;border-bottom-width:2px;padding-top:8px;padding-bottom:4px}#detail_decorate_root .magic-1{width:750px}#detail_decorate_root .magic-2{overflow:hidden;width:750px;height:928.2043530834341px;margin-top:0;margin-bottom:0;margin-left:0;margin-right:0}#detail_decorate_root .magic-3{margin-top:0;margin-left:0;width:750px;height:928.2043530834341px}#detail_decorate_root .magic-4{vertical-align:top}#detail_decorate_root .magic-5{vertical-align:top;display:inline-block;padding-right:4px;width:50%;box-sizing:border-box;margin-bottom:-4px;padding-left:0;margin-top:-4px}#detail_decorate_root .magic-6{vertical-align:top;padding-bottom:4px;box-sizing:border-box;padding-top:4px}#detail_decorate_root .magic-7{width:371px;height:371px;overflow:hidden}#detail_decorate_root .magic-8{position:relative;left:0;top:0;width:371px;height:371px}#detail_decorate_root .magic-9{vertical-align:top;display:inline-block;padding-right:4px;width:50%;box-sizing:border-box;margin-bottom:-4px;padding-left:0;margin-top:-4px;margin-left:-3px}#detail_decorate_root .magic-10{width:364px;border-collapse:collapse}#detail_decorate_root .magic-11{min-height:28px;padding:5px 10px;width:343px;min-height:18px;box-sizing:content-box}#detail_decorate_root .magic-12{text-align:left}#detail_decorate_root .magic-13{font-size:24px}#detail_decorate_root .magic-14{display:none}#detail_decorate_root .magic-15{min-height:28px;padding:5px 10px;width:251px;min-height:18px;box-sizing:content-box}#detail_decorate_root .magic-16{min-height:28px;padding:5px 10px;width:73px;min-height:18px;box-sizing:content-box}#detail_decorate_root .magic-17{min-height:28px;padding:5px 10px;width:250px;min-height:18px;box-sizing:content-box}#detail_decorate_root .magic-18{width:750px;border-collapse:collapse}#detail_decorate_root .magic-19{min-height:18px;padding:5px 10px;width:126px;min-height:18px;box-sizing:content-box}#detail_decorate_root .magic-20{text-align:center}#detail_decorate_root .magic-21{min-height:18px;padding:5px 10px;width:127px;min-height:18px;box-sizing:content-box}#detail_decorate_root .magic-22{min-height:18px;padding:5px 10px;width:193px;min-height:18px;box-sizing:content-box}#detail_decorate_root .magic-23{min-height:18px;padding:5px 10px;width:504px;min-height:18px;box-sizing:content-box}#detail_decorate_root .magic-24{overflow:hidden;width:750px;height:750px;margin-top:0;margin-bottom:0;margin-left:0;margin-right:0}#detail_decorate_root .magic-25{margin-top:0;margin-left:0;width:750px;height:750px}#detail_decorate_root .magic-26{overflow:hidden;width:750px;height:563px;margin-top:0;margin-bottom:0;margin-left:0;margin-right:0}#detail_decorate_root .magic-27{margin-top:0;margin-left:0;width:750px;height:563px}#detail_decorate_root .magic-28{border-bottom-style:solid;border-bottom-color:#53647a;font-family:Roboto;font-size:24px;color:#53647a;border-bottom-width:2px;padding-top:8px;padding-bottom:4px}#detail_decorate_root .magic-29{vertical-align:top;display:inline-block;padding-right:4px;width:33.33%;box-sizing:border-box;margin-bottom:-4px;padding-left:4px;margin-top:-4px}#detail_decorate_root .magic-30{vertical-align:top;box-sizing:border-box;padding-top:4px}#detail_decorate_root .magic-31{width:245px;height:245.00000000000003px;overflow:hidden}#detail_decorate_root .magic-32{position:relative;left:0;top:0;width:245.00000000000003px;height:245.00000000000003px}#detail_decorate_root .magic-33{padding:0;margin:0;white-space:pre-wrap;font-size:14px}#detail_decorate_root .magic-34{font-family:inherit;font-size:inherit;font-style:inherit;font-variant-ligatures:inherit;font-variant-caps:inherit}#detail_decorate_root .magic-35{position:relative;left:0;top:0;width:245px;height:245px}#detail_decorate_root .magic-36{width:245px;height:245px;overflow:hidden}#detail_decorate_root .magic-37{padding:0;margin:0;color:#333;font-size:14px;line-height:20px;font-weight:bold;white-space:pre-wrap}#detail_decorate_root .magic-38{overflow:hidden;width:750px;height:924px;margin-top:0;margin-bottom:0;margin-left:0;margin-right:0}#detail_decorate_root .magic-39{margin-top:0;margin-left:0;width:750px;height:924px}#detail_decorate_root .magic-40{overflow:hidden;width:750px;height:564px;margin-top:0;margin-bottom:0;margin-left:0;margin-right:0}#detail_decorate_root .magic-41{margin-top:0;margin-left:0;width:750px;height:564px}
Product information
Product Information | ||
Material |
Stainless Steel 304 2B and colored powder coating steel | |
Color |
White/red etc. | |
Type |
Pressurized | |
Collector |
Flate panel | |
Capacity |
100-500L | |
Certificates |
CE,CCC | |
MOQ |
20pcs | |
Model |
Collector Model |
Absorber
Area |
Tank Capacity
Liter |
Loading Quantity Sets/(20FT) |
JINFP-100-1 |
2000*1000-1PC |
2M² |
100 |
43 |
JINFP-150-1 |
2000*1000-1PC |
2M² |
150 |
36 |
JINFP-200-1 |
2000*1000-1PC |
2M² |
200 |
32 |
JINFP-200-2 |
2000*1000-2PC |
4M² |
200 |
27 |
JINFP-260-2 |
2000*1000-2PC |
4M² |
260 |
24 |
JINFP-300-2 |
2000*1000-2PC |
4M² |
300 |
22 |
JINFP-500-3 |
2000*1000-3PC |
6M² |
500 |
15 |
Inner Tank |
SUS304-2B 1.2mm(100 to 200 liters),above 200 liters thickness is 1.5mm |
Outer Tank |
Colored powder coating steel with thickness of 0.4mm |
Insulation layer |
55mm thick high density polyurethane |
Solar Flat Panel |
2000X1000X80mm, Selective Coating, Laser weldingaluminum alloy 6063-T5/white or black |
Heat Pipe |
14*0.6mm thick |
Tank Working Pressure |
4 bar, maximum testing pressure 12 bar. |
Collector Insulating Layer |
Fiber Glass, Thickness: 30mm, Glass Cover: Low Iron Tempered |
Warranty |
5 Years |
Delivery TIme |
Delivery time within 10 days after receiving deposit |
Payment Term |
TT/LC |
Packing |
Standard Export Packing |
MOQ |
20GP Containe (sample available) |
Product Show
