Busbyr Solar Inverter for Home Use 4200w 6200w with MPPT Charge Pure Sine Wave 4.2kw Solar Hybrid Inverter

Name: Busbyr Solar Inverter for Home Use 4200w 6200w with MPPT Charge Pure Sine Wave 4.2kw Solar Hybrid Inverter
SKU: 1005008919447211
Price: 429.91 EUR
Availability: InStock

429,91 €

26 people are viewing this product right now

🔥 6 items sold in last 3 hours

Add to compare

SKU: 1005008919447211

Category: Solar Inverters

Tag: Inverters

Description
Reviews (0)

Brand Name: XMSJ
Battery Included: No
Origin: Mainland China
Hign-concerned Chemical: None
Certification: CE
Place of Origin: Guangdong, China
Model Number: BSSI-V-GN
Brand Name: Busbyr
Input Voltage: 90-280 VAC 90VDC-450VDC
Output Voltage: 220/230/240VAC
Output Current: 18.2A – 27.0A
Output Frequency: 50Hz/ 60Hz
Output Type: DUAL Camera
Size: 500*415*180
Type: DC/AC Inverters
Inverter Efficiency: 98%
Weight: 11
Maximum Solar Charging Current: 120A-140A
MPPT Voltage Range: 60VDC-450VDC
Nominal Output Current: 18.2-27.0A
Power Factor: >0.99
Output Waveform: Pure sine wave
Nominal operating frequency: 50/60Hz
Nominal DC Voltage: 24VDC
Operating Temperature: -10-50℃
Color: Green blue
Product name: 4.2kw solar hybrid inverter

If you have any questions, Please contact our customer service
whatsApp：+86 15232159137
Email：kaigui8883@163.com

#detail_decorate_root .magic-0{width:750px}#detail_decorate_root .magic-1{overflow:hidden;width:750px;height:741px;margin-top:0;margin-bottom:0;margin-left:0;margin-right:0}#detail_decorate_root .magic-2{margin-top:0;margin-left:0;width:750px;height:741px}#detail_decorate_root .magic-3{width:750px;border-collapse:collapse}#detail_decorate_root .magic-4{min-height:28px;padding:5px 10px;width:316px;min-height:28px;box-sizing:content-box}#detail_decorate_root .magic-5{min-height:28px;padding:5px 10px;width:165px;min-height:28px;box-sizing:content-box}#detail_decorate_root .magic-6{min-height:28px;padding:5px 10px;width:203px;min-height:28px;box-sizing:content-box}#detail_decorate_root .magic-7{min-height:28px;padding:5px 10px;width:726px;min-height:28px;box-sizing:content-box}#detail_decorate_root .magic-8{display:none}#detail_decorate_root .magic-9{min-height:28px;padding:5px 10px;width:204px;min-height:28px;box-sizing:content-box}#detail_decorate_root .magic-10{margin-bottom:10px;line-height:0}#detail_decorate_root .magic-11{margin-bottom:0}#detail_decorate_root .magic-12{position:relative;width:100%}#detail_decorate_root .magic-13{overflow:hidden;width:750px;height:715px;margin-top:0;margin-bottom:0;margin-left:0;margin-right:0}#detail_decorate_root .magic-14{margin-top:0;margin-left:0;width:750px;height:715px}#detail_decorate_root .magic-15{margin-bottom:10px;overflow:hidden}#detail_decorate_root .magic-16{border-bottom-style:solid;border-bottom-color:#53647a;font-family:Roboto;font-size:24px;color:#53647a;font-style:normal;border-bottom-width:2px;padding-top:8px;padding-bottom:4px}#detail_decorate_root .magic-17{vertical-align:top}#detail_decorate_root .magic-18{vertical-align:top;display:block;padding-right:4px;box-sizing:border-box;padding-left:4px}#detail_decorate_root .magic-19{vertical-align:top;padding-bottom:4px;box-sizing:border-box;padding-top:4px}#detail_decorate_root .magic-20{padding:0;margin:0;white-space:pre-wrap;font-size:14px}

MODEL	BSSI-V-GN4200	BSSI-V-GN6200
Phase	1-phase	1-phase
Maximum PV Input Power	6200W	6500W
Rated Output Power	4200W/4200VA	6200W/6200VA
Maximum Solar Charging Current	140A	120A
GRID-TIE OPERATION
PV Input(DC)
Nominal DC Voltage/Maximum DC Voltage	360VDC/500VDC	360VDC/500VDC
Start-up Voltage/lnitial Feeding Voltage	60VDC/90VDC	60VDC/90VDC
MPPT Voltage Range	60VDC-450VDC	60VDC-450VDC
Number of MPPT Trackers/Maximum Input Current	1/18A	1/22A
GRID OUTPUT(AC)
Nominal Output Voltage	220/230/240VAC	220/230/240VAC
Output Voltage Range	195-253VAC	195-253VAC
Nominal Output Current	18.2A	27.0A
Power Factor	>0.99	>0.99
Feed-in Grid Frequency Range	49~51±1Hz	49~51±1Hz
EFFICIENCY
Maximum Conversion Efficiency(DC/AC)	98%	98%
TWO LOAD OUTPUT POWER
Full Load	4200W	6200W
Maximum Main Load	4200W	6200W
Maximum Second Load(battery mode)	1400W	2067W
Maximum Load Cut Off Voltage	26VDC	52VDC
Maximum Load Return Voltage	27VDC	54VDC

FAQ

1. who are we?

We are based in Guangdong, China, start from 2018,sell to Domestic Market(50.00%),Mid East(45.00%),Eastern Asia(1.00%),Southern Europe(1.00%),Africa(1.00%),Eastern Europe(1.00%),Southeast Asia(1.00%). There are total about 11-50 people in our office.

2. how can we guarantee quality?

Always a pre-production sample before mass production;

Always final Inspection before shipment;

3.what can you buy from us?

Solar Inverter

4. why should you buy from us not from other suppliers?

Innovative technology, high-tech R&D team, Excellent corporate culture

5. what services can we provide?

Accepted Delivery Terms: null锛�

Accepted Payment Currency:null;

Accepted Payment Type: null;

Language Spoken:null
